Home Products Stationary block machine QT5-15 Hydraulic PLC Controlled Hollow Brick Making Machine Automatic Gear-Driven Cement Block Moulding Machine
QT5-15 Hydraulic PLC Controlled Hollow Brick Making Machine Automatic Gear-Driven Cement Block Moulding Machine Stationary block machine
Stationary block machine
Concrete Machinery

QT5-15 Hydraulic PLC Controlled Hollow Brick Making Machine Automatic Gear-Driven Cement Block Moulding Machine

Products Description Main technical parameters Overall Dimension7400×1950×2800mmRated Pressure21MPaMain Vibration FormPlatform VibrationVibration Frequency2800~4500 ( r/min)Pallet Size1100*550mmMolding cycle15-25 (s)Overall Power26.5KWDemolding methodHydraulicApplied ProductsConcrete blocks. hollow/solid blocks. pavers. interlocking blocks . curbstone.colored pavers .etc.Raw MaterialCrushed stone. sand . cement. dust. and fly ash. gravel. slag. and other raw material . etc. Common blocks theoretical Capacity and common blocks samples […]

CE Certified
European Standards
Ships 15-30 Days
Fast Delivery
108+ Countries
Global Export
After-Sales Support
Training Included
Get Price & Quote WhatsApp Now
24h Response
Free Technical Consultation

Product Details

Products Description
Main technical parameters
Overall Dimension
7400×1950×2800mm
Rated Pressure
21MPa
Main Vibration Form
Platform Vibration
Vibration Frequency
2800~4500 ( r/min)
Pallet Size
1100*550mm
Molding cycle
15-25 (s)
Overall Power
26.5KW
Demolding method
Hydraulic
Applied Products
Concrete blocks. hollow/solid blocks. pavers. interlocking blocks . curbstone.colored pavers .etc.
Raw Material
Crushed stone. sand . cement. dust. and fly ash. gravel. slag.
and other raw material . etc.
Common blocks theoretical Capacity and common blocks samples
Item
Specification Size(L*W*H)
Qty/mold
(pcs)
Cycle Molding
Per hour
(Pcs)
Hollow brick
400*200*200mm
5
16-20s
1800pcs
Hollow block
400*150*200mm
6
15-20s
1300pcs
S paver
225*112.5*60mm
16
15-17s
3700pcs
Customer Visiting and customer working site
Packaging And Shipping
Company Profile

Shiyue Machinery is a professional manufacturer which is engaged in independently researching and developing. manufacturing and selling crushing equipment.block machine etc construction building machines. We have exported product to many countries. such as Mongolia. Russia. Philippines.India. Vietnam. Uzbekistan. Kyrgyzstan. Kazakhstan. Nigeria. South Africa.Oman .Botswana. America etc. What’s more.we receive good feedback about service and quality. We are not main for sales. but also for development of the market all over the world. Do our best to satisfy customers’ need and gurantee quality is our principal .With 27 years’ brick block machine manufacture & export experience.welcome all the customers to our company and build business relationship with us!
Our Service
1) Send the technicians to carry out the installation and debugging of equipment for the foreign users with compensation.2) Train the users to command the equipment and guide them for safe production.3) Explain the routine maintenance of equipment carefully and remove common faults.4) We are responsible for all the repairs that caused by our quality problems within one year’s warranty. (We will provide one set of spare parts/wear & tear parts free of charge with shipment.)5) For some countries whose visas are difficult obtained. customers can also send their technicians to our company to receive free guidance and training.6) Accept suggestions for improvement put forward by customers an earnest way. In accordance with changes of the market. provide the products and services to meet the user’s needs and create value for them.7) We will make every effort to solve your problems. and your success will add new glory to us.
