Home Products Stationary block machine QT4-15 Automatic Brick Making Machine
QT4-15 Automatic Brick Making Machine Stationary block machine
Stationary block machine
Concrete Machinery

QT4-15 Automatic Brick Making Machine

Product Description The QT4-15 Hydraulic Brick Making Machine Hollow Block Cement Making Machine is our newest design machine and controlled by the PLC. And this machine is considered to used with the middle and small factory. modelQT4-15 Hydraulic Brick Making Machine Hollow Block Cement Making MachineMolding cycle15-30spallets size900x500mmVibration typeplatform vibrationProduct height50-220mmoverall power24.5kwDemolding methodhydraulicVibration frequency50-70HZ features […]

CE Certified
European Standards
Ships 15-30 Days
Fast Delivery
108+ Countries
Global Export
After-Sales Support
Training Included
Get Price & Quote WhatsApp Now
24h Response
Free Technical Consultation

Product Details

Product Description
The QT4-15 Hydraulic Brick Making Machine Hollow Block Cement Making Machine is our newest design machine and controlled by the PLC. And this machine is considered to used with the middle and small factory.
model
QT4-15 Hydraulic Brick Making Machine Hollow Block Cement Making Machine
Molding cycle
15-30s
pallets size
900x500mm
Vibration type
platform vibration
Product height
50-220mm
overall power
24.5kw
Demolding method
hydraulic
Vibration frequency
50-70HZ

  • features of QT4-15 automatic block machine

1.This machine can use flyash. slag. gangue and other kind industrial residue then with sand. water. crushed stone. cement all kind material to make all kind hollow block. paver brick. solid bricks just changing the moulds.
 2.The whole process of this machine is controlled by PLC and powered by the hydraulic system. Monitoring with the approach switch. machinery. electric.hydraulic and vibrating system work together to make pallets feeding. material feeding. vibrating. demoulding process work automatically. And its characteristic is high efficient. easy-operated and easy-maintained.3.All the electrical and hydraulic parts are original imported or with China famous brand. So this machine is stable and with less faults.
4.Block molding mainly by hydraulic. machinery as sideline. vibrate and press to finish molding blocks. Our machine is assembled with our own patent vibrating system and with high power and frequency.5.The compressive strength of all blocks more than 15 MPa. compactness is high. impermeability and freeze resistance is better. and excellent capacity of sound insulation. heat insulation and dimensions are precise. the blocks are more consistency and low waster rate.
common blocks capacity and Block samples
blocks type
Size
(mm)
Molding cycle
Qty/Mould
(pcs)
Qty/hour
(pcs)
Qty/8hr
(pcs)
hollow blocks
400x200x200
15-20s
4
900-1200
7200-9600
hollow blocks
400x150x200
15-20s
5
1080-1440
8640-11520
hollow blocks

400x100x200

15-20s

8

1440-1920

11520-15360
paver mould

200×100*60

15-20s
16

2880-3840

23040-30720
solid mould

240x115x53

15-20s
28
5930-6720
47400-53700
Related Products
Packing&Shipping
After Sales Service
customer working site
after the machine delivery. we will offer service in these ways:
1.we will offer the machine foundation drawing. the electric wiring diagram. and the block machine operation manuel instruction book.
2.if necessary. we will sent engineer fly to customer site for installation and train until the worker can operate and maintain the machine skilled.
3.online video instruction and offer spare parts free.
Company Introduction
Linyi Youju Machinery CO.. LTD is a professional manufacturer which is engaged in independently researching and developing. manufacturing and selling crushing equipment.block machine etc construction building machines. We have exported product to many countries. such as Mongolia. Russia. Philippines.India. Vietnam. Uzbekistan. Kyrgyzstan. Kazakhstan. Nigeria. South Africa.Oman .Botswana. America etc. What’s more.we receive good feedback about service and quality. We are not main for sales. but also for development of the market all over the world. Do our best to satisfy customers’ need and guarantee quality is our principal .With 27 years’ brick block machine manufacture & export experience.welcome all the customers to our company and build business relationship with us.
