Stationary block machine
Best quality QT15-15 concrete block paving machineQT15-15 concrete block paving machineProduct DescriptionProduce Description 1.European design:material feeder cylinder is with turning arm. running faster. with high efficiency. feeding material more uniform.2. the upper mold synchronous gear are on two sides. the distance is large. the four points are more stable and the power is more evenly distributed. and […]
| Best quality QT15-15 concrete block paving machine |
| Produce Description |
1.European design:material feeder cylinder is with turning arm. running faster. with high efficiency. feeding material more uniform. 2. the upper mold synchronous gear are on two sides. the distance is large. the four points are more stable and the power is more evenly distributed. and the synchronization effect is better. 3.airbag. reduce vibration amplitude and noise. the pressure can be adjusted according to different brick types by changing the air pressure inside airbag. very easy and convenient. 4.Four external vibration motors. the total power is constant. the power of each motor becomes smaller. the starting load becomes smaller. the starting inertia becomes smaller. so the starting speed is faster.
|
| Machine Parts |
| Parameters | ||
| dimension | 9350*2520*2950mm | |
| weight | 15T | |
| power | 45.7kw | |
| voltage | 380v or according your needs | |
| certification | ISO9001:2008.CE | |
| Hydraulic | 21Mpa | |
| Pallet size | 1350×850×40mm | |
| color | according to your request | |
| warranty | 1 year | |
| Capacity |
| No. | Block photo | Block size | Pcs/mould | Pcs/hour | Pcs/day |
| 1 |  | 400*200*200 | 15 | 3600 | 28800 |
| 2 |  | 400*150*200 | 16 | 4320 | 34560 |
| 3 |  | 240*115*53 | 62 | 14000 | 112000 |
| Block machine sample |
The Main Advantages |
1.electric motor 2.CE&ISO9001 3.New product 4.Smart design 5.Factory for sale |
| Packaging&Shipping |
| Company Information |
Fill in your requirements and our export manager will respond within 24 hours with pricing, specs and a customized solution.
